Replacing or installing a roller garage door can feel bigger than it looks. There’s spring tension to respect, brackets to get dead square, headroom to check, and different fittings for standard, wind‑lock and chain‑operated doors. Get any of that wrong and you’ll fight a heavy door, chew through tracks, or risk a safety incident—especially with Australian sizes, fixings, and wind regions to consider.

This guide solves that by walking you through a clear, two‑person DIY method used by local installers. You’ll get the exact sequence—measure, mark, fix, lift, tension, and track—plus safety callouts at each step. We cover tools and fixings for timber, steel and masonry, how to set spring turns correctly, how to balance the door, and when to stop and recheck. You’ll also find quick links to official Australian installation PDFs (Taurean, B&D and more) so you can cross‑check specs for your specific model.

Here’s how we’ll tackle it: concise, numbered steps from site prep to final test; special notes for wind‑lock/wind‑strong installs; optional motor and safety beam setup; a maintenance checklist; and a troubleshooting section for common issues like coning, binding and poor balance. Ready to work safely and get it right the first time? Let’s begin.

Step 1. Know your door type and installation method (standard, windlock, chain-operated)

Before you measure or mount a bracket, confirm exactly which door you have. Your carton label and the roller door installation guide PDFs will state Standard (non‑windlocked), Windlock/Wind‑strong, or Chain‑operated. Each type changes the guides used, side clearances, lifting approach, and spring set‑up, so match your steps to the spec.

  • Standard (non‑windlocked): Uses regular C‑guides and typical U‑bolt clamping. Many manuals specify a curtain slightly wider than the opening—check your brand’s PDF.
  • Windlock/Wind‑strong: Heavier curtain with windlock clips and windlocked guides. Requires stricter clearances and the brand’s WindLock supplement; plan for a two‑person lift.
  • Chain‑operated: Fitted with a sprocket/chain hoist for tall or heavy doors or no power. Mount the hoist on the correct side and set chain routing/tension per the manual.

Step 2. Safety first: what to wear, two-person lift, and exclusion zone

Treat safety as the first step in any roller door installation. Wear proper PPE and plan a two‑person lift before touching the door roll. Keep the factory strapping on until the door is mounted and pre‑tensioned, and clear the workspace so nothing fouls ladders or guides during the lift.

  • Wear PPE: Gloves, safety boots, and safety goggles.
  • Set an exclusion zone: Establish a 2 m no‑go area under the opening; if you can’t maintain it, don’t proceed.
  • Two‑person lift: Use two step ladders and safe lifting methods (ropes/straps); never solo‑lift a rolled door.
  • Keep the strapping on: Do not cut bands until instructed during tensioning.
  • Stay organised: Keep tools within reach and confirm the structure is sound before you climb.

Step 3. Tools, fixings and what’s in the box

Before you start, gather tools and confirm fixings for your structure. Cross‑check with your model’s roller door installation guide so nothing slows the install.

  • Two step ladders
  • Laser/spirit level
  • Drill with bits, socket set, screwdrivers, pipe wrench
  • Tape, marker, knife, 400 mm softwood chock

Fixings: steel purlins use 4+ self‑drilling screws (supplied); timber uses 8 × 50 mm coach screws (supplied); masonry uses M8 bolts/threaded rod or 10 mm M8‑thread expansion anchors (not supplied). Use flat washers.

Box includes guides, brackets, U‑bolts/saddles, nuts/washers; lock is often clipped to the roll.

Step 4. Measure the opening: width, height, headroom, sideroom and backspace

Accurate measurements are the backbone of any roller door installation guide. Measure twice, write it down once, and match your notes to the brand PDF for your exact model. Use a laser or long level to pick up out‑of‑square openings and floor fall—these affect bracket lines, spring balance and guide tracking later.

  • Width (W): Brick-to-brick or frame-to-frame at top, middle, bottom; record the smallest.
  • Height (H): Finished floor to underside of lintel; check both sides.
  • Headroom: Lintel to ceiling/obstruction; must house the rolled curtain and fittings per your manual.
  • Sideroom: Clearance each side for guides. Typical: up to 3430 mm wide need ~25 mm/side; over 3430 mm need ~50 mm/side; windlock/light commercial ~50 mm/side (check your PDF).
  • Backspace: Internal depth behind the opening for the roll, guides and optional motor; verify against the manufacturer’s table.
  • Square check: Compare diagonals and note any floor slope; plan packers/shims if required.

Step 5. Prepare the opening and mark bracket lines

Good prep makes the fixing dead simple. Clear the opening, remove any protrusions, and ensure the lintel and jambs are sound and flush. Per every roller door installation guide, you’ll now set a level datum and mark where the brackets will sit so the axle ends land square and at the same height.

  • Clean and check: Scrape back render, pack or plane high spots so brackets bear flat.
  • Set a level datum: Use a laser to project the bracket seat height across both walls.
  • Mark inside lines: Measure the door curtain width, add the model’s required extra per side, and mark those inside bracket lines.
  • Mark fix points: Hold a bracket to the line, square it, and pencil hole centres (drill in the next step).

Step 6. Fix the first bracket square and solid

This is the anchor for the whole job, so take your time. Offer the first bracket up to your marked inside line at the laser datum, ensure the bracket face bears flat, then set it dead plumb and square to the opening. A precise, rigid first bracket makes spring tensioning and tracking painless later in the roller door installation guide.

  • Mark and drill: Pilot holes to suit your substrate.
  • Use correct fixings (with flat washers): Steel purlins—4+ self‑drilling screws; timber—3+ 8 × 50 mm coach screws; masonry—3+ M8 bolts/threaded rod or 10 mm M8‑thread expansion anchors.
  • Tighten, then re‑check: Nip up, confirm plumb/square, then fully tighten. Do not twist the bracket. Keep the second bracket loose for the next step.

Step 7. Level across and fix the second bracket

Level the second bracket off the first so the axle runs true—any twist causes binding or coning. Transfer your laser datum, align to the inside line, and make sure both bracket faces sit in the same plane. Confirm bracket‑to‑bracket matches the axle spec in your roller door installation guide before you drill.

  • Hold to marks; set plumb and square.
  • Pilot‑drill, then fix with correct hardware and flat washers; nip, re‑check, tighten.
  • Re‑check level to the first bracket; slots mirror, axle seat centred. Pack only to correct wall irregularities.

Step 8. Lift the rolled door onto the brackets (correct orientation)

With two people on step ladders, use ropes/straps to lift the rolled door safely. Keep the factory strapping on. Present the roll so it will unroll down the front of the opening, with the bottom rail finishing on the inside of the garage. Lower the axle stubs into the bracket slots and make sure the roll is bearing evenly on both brackets. Do not release your grip or cut straps yet—hands clear of pinch points. This roller door installation guide hinges on getting orientation right.

  • Face the roll correctly: Curtain unrolls down the front.
  • Bottom rail inside: Ends up inside the garage when lowered.
  • Axle seated: Stubs fully in slots, roll level on both brackets.

Step 9. Centre the axle and loosely clamp with U-bolts

With the roll seated, centre the axle in the opening so the curtain tracks true—this quick step, noted in every roller door installation guide, prevents binding and coning. You’re only positioning now, not locking anything solid.

  • Equal reveal: Set equal curtain overlap at both jambs; nudge the roll until centred.
  • Axle alignment: Keep axle stubs equally positioned in the bracket slots and the roll level.
  • Loose clamp: Fit U‑bolts and saddles with washers; nip nuts only so the axle can still rotate. Recheck centring and shared load.

Step 10. Pre‑tension the spring to spec

This is the moment the door gets its “feel”. You’ll wind the spring so the curtain is light and controllable by hand. Follow your brand PDF for the exact number of turns—spring turns vary by door size and model—then lock everything evenly. A careful, controlled wind now saves chasing balance later in the roller door installation guide.

  • Fix the axle to the brackets: Fit washers/nuts to the bracket studs and nip up firmly.
  • Hold the axle; rotate the door: With a pipe wrench gripping the axle, rotate the rolled curtain forward (down the front) to add tension.
  • Count your turns: Mark a reference line and count full rotations per the manufacturer’s spec.
  • Keep clear and in control: Maintain two‑person control; never let the roll “run”.
  • Lock off evenly: At target turns, tighten U‑bolt saddles evenly and re‑check centring before proceeding.

Step 11. Cut the strapping and lower the curtain onto a chock

With the axle pre‑tensioned and U‑bolts nipped, you can remove the factory bands. As every roller door installation guide notes, stay two‑up and have a softwood chock ready under the bottom rail.

  • One person holds the axle while the other carefully cuts the strapping.
  • Lower the curtain in control—don’t let it run; hands clear.
  • Set a 400 mm softwood chock centrally and rest the bottom rail on it until the tracks are on.

Step 12. Fit and plumb the first guide track

With the curtain resting safely on the chock and equal overlap confirmed, slide the first guide track fully onto the curtain edge. Bring the track to your marked inside line, hold it tight to the wall, and use a spirit level to set it perfectly plumb. Loosely fix through the slotted holes so you can fine‑tune. The aim, per every roller door installation guide, is a straight, plumb and parralel track with the curtain moving freely—no rub, no pinch.

  • Pick your best fixing side first: Choose the straighter, stronger jamb.
  • Set it plumb, then tack: Lightly fasten; leave adjustment room.
  • Check curtain movement: Lift/lower slightly—no binding in the mouth of the guide.
  • Re‑check your lines: Inside mark, plumb, and bracket plane must agree.
  • Windlock note: Ensure windlock clips engage the windlocked guide profile per the supplement.

Step 13. Fit the second track and check clearances

With the first guide tacked and the curtain resting on the chock, slide the second guide fully onto the curtain edge. Bring it to your inside line, set it perfectly plumb, and tack it off. Now hand‑cycle the door a little up and down; this is where a roller door installation guide saves time—smooth travel before final tightening.

  • Confirm parallel guides: Measure between guides at top, mid, bottom.
  • Check for rub/pinch: Adjust guide in/out so the curtain runs free.
  • Stay in the same plane: Guides must align with bracket faces; pack if needed.
  • Tighten top‑down: Once movement is smooth, tighten fixings with washers.
  • Windlock check (if applicable): Every clip must engage the windlocked guide profile.

Step 14. Fit bottom rail hardware: handle, lock and weight bar

With the guides tightened and the curtain travelling freely, fit the bottom‑rail hardware. The weight bar stiffens the span, the handle gives safe manual control, and the lock secures the opening. If you’ll motorise the door, leave any mechanical lock disengaged as many manuals advise. Your lock (if ordered) is often clipped to the end of the roll.

  • Fit the weight bar: Slide into the bottom rail channel, align pre‑punched holes, fix with supplied screws/bolts; keep the weather seal straight.
  • Install the handle: Centre on the exterior face of the bottom rail; drill/fasten per the kit template; ensure fixings don’t foul the guides.
  • Fit the lock kit (if used): Insert the cylinder through the bottom rail holes, attach the backing plate, set rods/receivers to length and confirm smooth engagement per the brand’s roller door installation guide; don’t lubricate the lock.
  • Final clearance check: Cycle the door slowly—no snagging at guides; trim/seat the weather strip if required.

Step 15. Test run and perform a balance test

With both guides tightened and the bottom rail gear on, remove the chock and hand‑cycle the door several times. Stay two‑up, keep the 2 m exclusion zone, and move slowly. This is the point in any roller door installation guide where you find small issues before they become big ones.

  • Smooth travel: Lift and lower—no scraping, binding or “catch” at guide mouths.
  • Even overlap: Check equal reveal at both jambs through the full travel.
  • Floor contact: Bottom seal touches evenly; no hard spots or gaps.
  • Balance test: Close the door, then lift to waist height. If it stays put, tension is correct. Rises = too much tension; drops = not enough (note for Step 16).
  • Controlled movement: Door shouldn’t “run away” when near open/closed; effort should be light and even.
  • Final check: Re‑nip bracket/guide fixings after the first full cycles.

Step 16. Adjust spring tension safely if needed

If the balance test showed the door rising or dropping at waist height, adjust spring tension a turn at a time. Springs hold serious energy—work two‑up, maintain the 2 m exclusion zone, and only proceed if you’re confident following your roller door installation guide.

  1. Tie ropes to both ends; control the roll with pipe wrenches.
  2. Loosen U‑bolt nuts while maintaining a firm grip on the axle.
  3. Rotate axle clockwise to add tension, anticlockwise to reduce; move in small increments.
  4. Re‑tighten evenly, test and repeat until it holds at waist height.

Step 17. Optional: install a roller door opener and safety beams

Only fit a motor once the door moves smoothly and passes the balance test—never use a motor to hide a tight or poorly set door. Most Australian openers are plug‑in units, so follow the opener manual alongside this roller door installation guide. Disengage any mechanical lock and make sure the manual release cord is reachable from the floor.

  1. Confirm balance and clearances: Door must lift by hand easily with no binding.
  2. Mount the motor: Fix the bracket above door centre into solid structure; level and square.
  3. Attach the drive: Fit the drive shaft/coupler per the kit and set correct length/alignment.
  4. Install safety beams: Mount at each jamb near floor level; align LEDs until steady.
  5. Cable and power: Route leads neatly; plug into a nearby outlet—no hard‑wiring.
  6. Program settings: Set travel limits, close/open force and code remotes.
  7. Test safety: Check auto‑reverse on a 40 mm obstruction and beam interruption; verify manual release works. Re‑check all fixings after several cycles.

Step 18. Special notes for windlock/wind‑strong installs

Windlock and wind‑strong doors are heavier and use windlocked guides with locking clips that must engage cleanly along the full travel. Work strictly to your brand’s WindLock supplement alongside this roller door installation guide. Clearances are tighter, side space is typically greater than standard, and a disciplined two‑person lift is non‑negotiable. The aim is smooth clip‑to‑guide engagement with zero pinch, rub or missed locks before you tighten off.

  • Use windlocked guides only: Match left/right correctly and keep them in the same plane.
  • Check side clearances: Allow the manufacturer’s required sideroom (often ~50 mm each side).
  • Set tension per manual: Do not guess spring turns; heavier curtains vary by size/model.
  • Prove clip engagement: Hand‑cycle slowly; every windlock clip must seat in the guide profile.
  • Fix into solid structure: Use the specified fasteners and washers; tighten top‑down after proving travel.
  • Re‑test under load: Multiple slow cycles before fitting an opener; any bind means re‑align, not “more force”.

Step 19. Maintenance schedule and care tips

Routine care keeps your door smooth, quiet and safe. Most Australian manuals call for a six‑monthly check—quarterly in dusty or coastal sites. Follow this roller door installation guide’s safety habits and don’t attempt spring work unless you’re confident.

  • Clean the curtain: Mild detergent; rinse promptly.
  • Inspect and re‑tighten: Brackets, guides, U‑bolts; check cables/seal.
  • Lubricate springs only: Never the lock.
  • Tracks: Don’t oil; wipe with a spirit‑based cleaner.
  • Balance test: At waist height; adjust only if competent.

Step 20. Troubleshooting common issues

Even careful installs can throw up snags. Work two‑up, keep your 2 m exclusion zone, and use this quick diagnostics list alongside your roller door installation guide to correct issues without masking them with extra force or motor power.

  • Door “cones” (layers walk sideways): Re‑centre the axle, set guides exactly parallel, loosen U‑bolts, re‑tension evenly, then re‑tighten.
  • Binding in guides: Loosen fixings, re‑plumb and align guides in the same plane; clean guides—don’t oil them.
  • Too heavy or too light: Adjust spring tension in small turns, then re‑do the waist‑height balance test.
  • Door “runs away”: Reduce spring tension 1–2 turns; confirm U‑bolts are tight and even.
  • Bottom seal gaps one side: Compensate for floor fall by shimming guide feet; trim seal only as a last resort.
  • Lock won’t engage: Reset rod length/receivers and square the bottom rail; do not lubricate the lock.
  • Opener won’t close/auto‑reverses: First fix balance; set limits/force correctly and align safety beams until LEDs show solid.
  • Windlock clips pop out: Re‑align windlocked guides, verify required sideroom, and hand‑cycle to confirm every clip engages along the travel.

Step 21. Downloadable Australian installation PDFs and support

Prefer to follow the brand PDF alongside this roller door installation guide? We host the latest Australian manuals so you can match steps to your exact door and wind rating. Download the model‑specific instructions before you start and keep them on hand during the install.

  • Taurean Doors: Series A, Series AA, Series B, NovaTaur Residential, NovaTaur Commercial, WindLock Supplement, Classic Sectional, “What’s in the Parts Box”.
  • B&D Doors: Series 1/2/3 Installation Guides plus Series 1/2/3 Framing Details.

Need help or a quick double‑check? Call +61 450 731 865 or email doorsaus@gmail.com with your measurements, photos and order number for fast support.

Before you go

If you’ve followed the steps, you’ve now got a smooth, balanced door that opens with fingertip control and closes securely. Keep to the maintenance rhythm, respect spring tension, and don’t hesitate to pause and re‑check alignment if anything feels off—especially on windlocked setups where clip engagement matters.

  • Tighten every fixing you touched; re‑check bracket and guide screws after final cycles.
  • Repeat the waist‑height balance test; adjust in small turns if needed.
  • Confirm the bottom seal sits evenly on the floor.
  • If motorised, make sure safety beams are aligned and the manual release is accessible.
  • Leave mechanical locks disengaged when using an opener.
